Slitting & Rewinding MachineWelcome to PPD Film Rewinder Machinery

The polypropylene film slitter rewinder is suitable for slitting various plastic films, such as polyprolene film, LDPE film, PET film, Opp film, CPP film, CPE film and food packaging film etc. Features: 1. Main Motor equipped with inverter for


speed
regulation.
2. Separate General Control Cabinet, more flexible and easier operation.
3. Equipped with air shaft for unwinding material loading, magnetic powder brake
4. Air shaft for rewinding, Magnetic powder clutch for rewinding tension control
5. Automatic meter counting device.
6. Pressure roller for rewinding to make the rewinding roll more uniform.

Main Data:

Name:Polypropylene Film Slitter Rewinder

Model:PPD-PF1100

Material Thickness:0.02-0.04mm

Max.Width of Mother Roll:1100mm

Max.Diameter of Mother Roll:600mm

Width of Final Roll:50~1100mm option

Max.Diameter of Rewinding:400mm

Internal Diameter of Roll Core:76mm

Mechanical Speed:200m/min

Slitting and Rewinding Speed:160m/min

Total Power:4kw

Voltage:380V

Packing Size:2200*1600*1600mm

Weight:1200kg

NOTE:Different sizes can be customized.
