Stretch Film RewinderWelcome to PPD Film Rewinder Machinery

The fully automatic pre stretch fluffy roll rewinder is our latest design for rewinding pre stretch film fluffy rolls.
It is a multi-functional fully automatic rewinder, incorporating rewinding, pre stretching, edge folding, swing, fluffy etc.

Features:
1. The machine is suitable for pre stretch and general rewinding of industrial stretch films
2. With different gears, different stretching ratios can be obtained, and the film can be stretched at different different thickness and width;
3.PLC + HMI + Inverter control system, simple in operation and high efficiency.

Main Data:

Name:Fully Automatic Pre Stretch Fluffy Roll Rewinder

Model:PPD-APRW600-F

Width of mother roll:600mm

Width of finish roll:max600mm

Mother roll OD:max400mm

Finish Roll OD:max 180mm

Core of mother roll:3inch

Core of finish roll: 1.5/2/3inch

Pre stretching speed: max600/min

Standard roll rewind speed:max900m/min

Voltage:220/380/415V option
