The automatic foil container stacker is one of the main components of the aluminum foil container production machine.

It is used to stack the finished products of the aluminum foil container, make the packing of the aluminum foil container easier.



Features:

1. It can collect, count, note, stacker and unload aluminum foil containers automatically and independently.

2.The width of the stacker ways can be regulated according to the size of the container. It is possible to stack containers of different dimensions.

3. The stacker is suitable for all container shapes: rectangle, round, square.

Main data:

Name:Automatic Foil Container Stacker

Model:PPD-S

Conveyor Belt width: 750mm

Receipt with The Height: 900-1200mmcan be adjusted);

Foil Container Minimum Size: 100*100mm(can be adjusted)

Foil Container Maximum Size): 600*350mm (1 lane); 250*350mm(2 Lanes)

Maximum Stacking Height: 500mm or according to the size of foil container

The Largest Pile Number: 120 pcs

Maximum stacking speed: 50 pcs/min

Air Consumption: 0.2m³/min(1lane)

Machine Power: 3KW

NOTE:Different sizes can be customized.
