New Design Coreless PE Stretch Wrap Film Rewinder

PPD-CSFR1000
New design coreless PE stretch wrap film rewinder is our latest model to rewind PE stretch film roll from large jumbo roll to small diameter roll without paper tube.
It is a multi-functional model, it can slit the PE stretch film roll into several small width rolls as a standard slitting rewinding machine.

Features:
1. For standard slitting mode: can set different width, such as 50mm,100mm,200mm,300mm,500mm, max to jumbo roll width, core size: 1.5/2/3inch 2. For in corelss rewinding mode: same width
as jumbo roll size, rewind roll coreless size: 76mm air shaft

Main Data:

Name:New Design Coreless PE  Stretch Wrap Film Rewinder

Model:PPD-CSFR1000

Jumbo roll width:1000mm

Jumbo roll ID:76mm(3inch)

Jumbo roll OD:max500mm

Rewind roll width:50-1000mm option

Rewind roll length:max450m

Rewind roll paper core ID:38mm,50mm,76mm

Rewind roll coreless ID:76mm

Speed:max300/min

Voltage:220/380/415V,50hz,3ph

NOTE:Any specifications can be customized.
